KFG301Z Special Transformer Collection Terminal Type Ⅰ

KFG301Z dedicated transformer acquisition terminal type I is used for large dedicated transformer users with contracted capacity of 100kVA and above

Wireless private network/4G/5G can be selected as the communication channel to realize the collection of power information of dedicated transformer users

The user's power load and power consumption are monitored, and the collected data is managed and transmitted, etc

Key Features

Intelligent and efficient
  • With configuration function, the device parameters can be easily modified locally/remotely, and local/remote software online upgrade is supported
  • Adopt industrial-grade ARM series system motherboard and LINUX operating system
  • Large-capacity storage design ensures fast and safe storage of large amounts of data
Safe and reliable
  • It has excellent magnetic field compatibility and can resist interference from high voltage spike pulses, strong magnetic fields, strong static electricity, and lightning surges, and has a strong range of environmental adaptability
  • Query the customized settings of power control period and the setting of power purchase control parameters
  • Multi-loop control, supporting loop expansion, meeting load control management requirements
Flexible configuration
  • Remote communication using 4G/5G and Ethernet
  • Communication interface: 2 RS-485 interfaces, 2 CAN interfaces, 1 RS-232 interface
  • I/O port: 8-way state input, 8-way pulse input, 8-way control output (three-phase four-wire, 220V/1.5A)
  • Automatic maintenance function of energy meter communication parameters
  • Software and hardware decoupling design, application software APP, customizable functions
Applicable scenarios
  • Used for the implementation and transformation of power automation in various urban power grids, rural power grids, and enterprise power grids
